最大钻孔深度m

Maximum drilling depth.(m)

30

最大钻孔直径mm

Maximum drilling diameter .(mm)

3000

发动机额定功率KW/rpm

Engine rated power.(KW/rpm)

184

行走驱动

四驱

动力头最大扭矩kN.m

Maximum torque of power head.(KN.m)

120

动力头转速rpm

Power head speed.(rpm)

10-50

液压系统最大工作压力主泵MPa

Maximum working pressure of hydraulic system main pump.(MPa)

31.5

液压系统最大流量主泵L/min

Maximum bow rate of the main pump hydraulic system.(L/min)

120

加压系统最大加压力KN

Maximum pressurization force of the pressurization system(KN)

100

加压系统最大提升力KN

Maximum lifting force of the pressurization system(KN)

80

加压系统最大行程m

Maximum stroke of the pressurization system(m)

2.5

主卷扬最大提升力KN

Maximum lifting force of the main winch.(KN)

12

主卷扬最大提升速度m/min

Maximum lifting speed of the main winch(m/min)

50

副卷扬最大提升力KN

Maximum lifting force of the auxiliary winch.(KN)

1.5

副卷扬最大提升速度m/min

Maximum lifting speed of auxiliary winch(m/min)

50

钻桅左右倾角°

Left and right inclination angle of drilling mast(°)

±5

钻桅前倾角°

Forward and backward inclination angle of the drilling mast. (°)

±5

工作状态宽度mm

Overall width of working state.(mm)

3500

运输状态长度mm

Overall length of transport status.(mm)

10100

运输状态宽度mm

Overall width of transport status.(mm)

3000

运输状态高度mm

Overall height of transport status.(mm)

3750
